Performance
|
|
| Opening speed: |
Normal opening speed 0.2 – 0.3 m/s |
| Size range: |
Max. Clearance Width 14m x clearance height 16m. |
| Wind Load: |
0.7 – 1.6 kPa depending on size (class 3 – 5, EN 12424), can however be designed for higher wind loads on request. |
Electrical system
|
|
| Power Supply: |
3-phase 208, 230, 460, 575 Volt; 60 hertz. |
| Control Voltage: |
110 VAC. |
| Motor Ratings: |
2 to 5 Hp. per motor. Doors are supplied in either single or dual motor versions. The dual motor system is supplied for doors with CH > 30 feet. |
Fabric data
|
|
| Unchanged Pliability: |
-35°C to +70°C |
| Tensile Strength: |
Warp : 2700N/5 cm acc. DIN 53354, EN ISO 1421 Weft : 2500N/5 cm acc. DIN 53354, EN ISO 1421. |
| Resistance to Light: |
6 – 8 (on a scale 0-8) acc. BS 1006 ≥ 7 acc. ISO 105-B02. |
| Resistance to UV-rays: |
UV-stabilized. |
| Flame resistance: |
Yes, acc. SIS 650082, ASTM E84-94 class A, DIN 4102 B1. |
Surface treatment
|
|
| Steel Parts: |
Alkaline cleaned or sandblasted. Powder epoxy finish paint. |
| Sheet Profiles: |
Hot-galvanized steel sheet with primer and finish paint. |
| Bottom Profile: |
Sandblasted and primed. |
| Side Jambs (frame): |
Sandblasted and primed. |
| Other Parts: |
Aluminum, High Density Plastic, Stainless Steel, Zinc / Cadmium plated. |
